Type MPR20 N 24V 300 A
0 - Yorum Yap
Kategori
Marka
Stok Kodu
CBAYZG54B7
Fiyat
250,00 EUR + KDV
Havale
12.199,82 TL
(%2,00 havale indirimi)
%16 İNDİRİM
12.448,80 TL
KDV DAHİL
10.374,00 TL
KDV HARİÇ
12.199,82 TL
HAVALE FİYATI
Bu ürünü 1.279,74 TL’den başlayan taksit seçenekleriyle alabilirsiniz.
TYPE MPR20 N 24V 300 A
| Voltage rating | DC 24 V |
|---|---|
| Operating voltage | DC 16...32 V |
| Continuous current | 300 A |
| Number of poles | 1-pole |
| Physical isolation of load circuit | 1 (NO) |
| Temperature range | -40° C … +85° C |
| Terminal design | Load terminals M8 or M10 Control terminals M4 resp. HDSCS |
| Mounting method | M4 connectors side and foot foot flange holes with compression limiter side flange |
| Design | Cylindrical enclosure |
| Feature | Mechanical power relay for harsh application conditions. Extremely power saving due to a bistable drive, which only needs energy during switching operations. |
| Contact system type | mechanical |
APPLICATIONS
- Automated guided vehicles (AGV)
- Automobiles
- Commercial Vehicles
- Forklifts
- Rail vehicles
- Watercraft & Vehicles
